Sinocastel wireless long live battery asset GPS tracker LT-164

FOB Reference Price:Get Latest Price
$1.00 - $34.00 / Piece | 10 Piece/Pieces (Min. Order)
Screen Size:
india telematics
Memory Capacity:
none
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Type:
GPS Tracker, mini asset GPS tracker
Use:
Automotive
Function:
india telematics
Place of Origin:
Guangdong, China
Brand Name:
SINOCASTEL
Model Number:
LT-160
Warranty:
12 Months
Battery:
5000mAH rechargeable
Accuracy:
2.5m (optimal)
Working Temperature:
-20℃~70℃
Size:
90mm(L)*57mm(W)*26mm(H)
Long standby GPS Tracker Location:
Real-time GPS positioning
Long standby GPS Tracker Alarm:
Anti disassemble/Low battery Alarm
Long standby GPS Tracker network:
GSM 850/900/1800/1900MHz
Material:
Industrial grade high strength plastic
Installation:
No need any installation
Supply Ability
Supply Ability:
60000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1pc/gift box;48pcs/ctn
Port
Shenzhen

Sinocastel wireless long live battery asset GPS tracker LT-164



LT-164 is a rechargeable long stand-by GPS tracker with exquisite appearance and small size. It can be installed on any moving target objects without any external wires. It has built-in super Li-battery which supports working continuously for 50 hours after charging fully and 800 hours in the power saving state for the stand-by. It supports GPS, AGPS and LBS location.






Feature

1.2.1 Rechargeable ultra-long standby positioning monitoring terminal

1.2.2 Built-in large-capacity industrial-grade rechargeable polymer lithium battery with capacity and voltage respectively for 5000mAH, 3.6V

1.2.3Long working hours and standby time, which can work for 50 hours under normal working condition and keep standby for about 800 hours under the power saving state

1.2.4 Defined normal working state: regardless of the GPS signal, GSM module and positioning module are all working normally without sleeping and uploads one position information every 15S

1.2.5 Defined power saving state: GSM sleeps and wakes up periodically (default interval is 10 minutes) to upload a message; the positioning module is completely disabled and imprecise positioning; under this state, the device can be awakened at any time by phone, SMS and GPRS.

1.2.6 Equipped with high sensitivity and low power consumption three-axis G-sensor acceleration sensor to monitor the working environment of the equipment in real time, restrain static drift, and automatically switch the working mode of the equipment.

1.2.7 Supports the most common micro-USB interface charging in the market at present, compatible with most mobile phone chargers with charging specification of DC5V and 1A.



Product Features

Description

Working Frequency

4 frequency:GSM 850/900/1800/1900MHz

Maximum Transmitting Power

GSM850 Class4(2W)

GSM900 Class4(2W)

DCS1800 Class1(1W)

PCS1900 Class1(1W)

Receive Sensitivity

<-107dBm

Working Temperature

-35℃~80

Storage Temperature

-45℃~90

Working Voltage

3.3V~4.6V(recommend 4.0V)

Power Consumption

GPRS Class10 Max:460mA; Current of shutting off : 47uA

GPRS

GPRS Class 10,Embedded TCP/IP stack

Maximum downlink transmission rate:85.6kbps

Maximum upstream transmission rate:85.6kbps



Authentication Information

ROHS, FCC, CE Type Approval









1.what is OBD&OBDII?

OBD(On-board diagnostics)is an automotive term referring to a vehicle's self-diagnostic and reporting capability. OBD systems give the vehicle owner or repair technician access to the status of the various vehicle sub-systems. Modern OBD implementations use a standardized digital communications port to provide real-time data in addition to a standardized series of diagnostic trouble codes, or DTCs, which allow one to rapidly identify and remedy malfunctions within the vehicle.

2.what is the obd gps tracker?

gps tracker intergrate with OBD protocol

3.what is the different OF 213GD, IDD-213W, IDD-213LA,IDD-213LE and 213LC?

213GD for global GSM band,213W for Global band,213LA for North and South America, 213LE for Europe or some South East Country like Malaysia, Singapor, Thailand. 213LC for Asia Country

4.You obd gps tracker support or doesn't support SIM card

All obd serial product Support SIM card

5.How does the device work?

download PCTOOL from Sinocatel website, use USB cable connect computer set APN and others data, plug and play with vehicle.

6.what is the Frequency of the simcard?GSM and WCDMA?

GSM Frequency: 850/900/1800/1900MHz, WCDMA Frequency:800/850/900/2100(Europ),800/850/1700/1900(North America)

7.Does your tracker have SMS alerts?

Yes, SMS alerts from phone

8.Does your system have demo test account?

yes, test account:demotest, password:123456

9.Does your system free to use?

free half year, get pay after half year, can provide the charge list if you need.

10.Does your system have smartphone APP?

yes, APP name UUAID and Palm fleet, download from wesbite.
